RP10-1212DA
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 10W 9-18VIN +/-12VOUT
PDF
/
Inventory: 6750
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module
Technical
Operating Temperature -40°C~80°C
Packaging Tube
Series POWERLINE RP10-A (10W)
Size / Dimension 1.00Lx1.00W x 0.39 H 25.4mmx25.4mmx9.9mm
Feature OCP, OVP, SCP, UVLO
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 10W
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 2
Efficiency 89%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 18V
Max Output Current 416mA
Voltage - Output 1 12V
Voltage - Input (Min) 9V
Current - Output (Max) 416mA 416mA
Output Power 10W
Voltage - Output 2 -12V
Dimensions
Height 9.906mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
