RP08-4815DA
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 9 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 8W 36-75VIN +/-15VOUT
PDF
/
Buying Options
Total Price: USD $47.97
Unit Price: USD $47.97412
≥1 USD $47.97412
≥10 USD $45.25861
≥100 USD $42.6968
≥500 USD $40.28
≥1000 USD $38
≥3000 USD $35.84906
Inventory: 1935
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 31.8mm
Height 10.2mm
Technical
Nominal Input Voltage 48V
Total Power Output-Max 8W
Voltage - Output 2 -15V
Max Output Voltage 15V
Control Features Enable, Active High
Output Power 8W
Output Current 267mA
Current - Output (Max) 267mA 267mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Max Output Current 267mA
Output Voltage 15V
Voltage - Input (Max) 75V
Voltage - Isolation 1.6kV
Efficiency 87%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XDMA-P9
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 8W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OCP, OVP, SCP
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Series POWERLINE RP08 (8W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 16g
Package / Case 24-DIP Module, 9 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
