RO-3.305S/HP
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 3.3VIN 05VOUT
PDF
/
Buying Options
Total Price: USD $7.29
Unit Price: USD $7.29308
≥1 USD $7.29308
≥10 USD $6.880269
≥100 USD $6.490814
≥500 USD $6.123414
≥1000 USD $5.776803
Inventory: 1962
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 10mm
Technical
Isolation Isolated
Nominal Input Voltage 3.3V
Total Power Output-Max 1W
Max Output Voltage 5V
Output Power 1W
Output Current 200mA
Trim/Adjustable Output NO
Input Voltage-Nom 3.3V
Voltage - Input (Min) 3V
Max Output Current 200mA
Output Voltage 5V
Voltage - Input (Max) 3.6V
Voltage - Isolation 2kV
Efficiency 80%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 6mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.45Lx0.24W x 0.39 H 11.5mmx6.0mmx10.0mm
Series ECONOLINE RO (1W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 1.4g
Number of Pins 4
Package / Case 4-SIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
