RO-243.3S/H
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 24VIN 3.3VOUT
PDF
/
Buying Options
Total Price: USD $7.57
Unit Price: USD $7.57486
≥1 USD $7.57486
≥10 USD $7.1461
≥100 USD $6.7416
≥500 USD $6.36
≥1000 USD $6
≥3000 USD $5.66038
Inventory: 7485
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Height 10mm
Technical
Nominal Input Voltage 24V
Total Power Output-Max 1W
Max Output Voltage 3.3V
Output Power 1W
Output Current 303mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 21.6V
Max Output Current 303mA
Output Voltage 3.3V
Voltage - Input (Max) 26.4V
Voltage - Isolation 2kV
Efficiency 75%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-P4
Pin Count 4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.45Lx0.24W x 0.39 H 11.5mmx6.0mmx10.0mm
Series ECONOLINE RO (1W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 1.4g
Package / Case 4-SIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
