RO-2412S/HP
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 24VIN 12VOUT
PDF
/
Buying Options
Total Price: USD $6.31
Unit Price: USD $6.31238
≥1 USD $6.31238
≥10 USD $5.95508
≥100 USD $5.618
≥500 USD $5.3
≥1000 USD $5
≥3000 USD $4.71698
Inventory: 1152
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-SIP Module
Weight 1.4g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series ECONOLINE RO (1W)
Size / Dimension 0.45Lx0.24W x 0.39 H 11.5mmx6.0mmx10.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Subcategory Other Analog ICs
Max Power Dissipation 1W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 4
JESD-30 Code R-XSMA-P4
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 84%
Voltage - Isolation 2kV
Voltage - Input (Max) 26.4V
Output Voltage 12V
Max Output Current 83mA
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Output Current 83mA
Output Power 1W
Max Output Voltage 12V
Total Power Output-Max 1W
Nominal Input Voltage 24V
Dimensions
Height 10mm
Width 6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
