RO-1224S
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Recom Iso DC-DC Converter; Vin 10.8 to 13.2Vdc; Vout 24Vdc; I/O isolation 1000Vdc
PDF
/
Buying Options
Total Price: USD $5.72
Unit Price: USD $5.72
≥1 USD $5.72
≥10 USD $5.64256
≥100 USD $5.56072
≥500 USD $5.396864
≥1000 USD $5.233184
≥3000 USD $5.06968
Inventory: 1158
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 6mm
Height 10mm
Technical
Min Input Voltage (DC) 10.8V
Max Input Voltage (DC) 13.2V
Nominal Output Voltage 24V
Isolation Isolated
Max Output Power 1W
Nominal Input Voltage 12V
Current - Output 1 42mA
Max Output Voltage 24V
Output Power 1W
Output Current 42mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Max Output Current 42mA
Output Voltage 24V
Voltage - Isolation 1kV
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 11.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Power Rating 1W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.45Lx0.24W x 0.39 H 11.5mmx6.0mmx10.0mm
Series ECONOLINE RO (1W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 1.4g
Number of Pins 4
Package / Case 4-SIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
