RN-0509S
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1.25W 05VIN 09VOUT
PDF
/
Inventory: 3166
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 7.62mm
Technical
Switching Frequency 105kHz
Max Output Power 1.25W
Nominal Input Voltage 5V
Max Output Voltage 9V
Output Power 1.25W
Output Current 140mA
Voltage - Input (Min) 4.5V
Max Output Current 140mA
Output Type Fixed
Output Voltage 9V
Voltage - Input (Max) 5.5V
Voltage - Isolation 1kV
Efficiency 80%
Qualification Status Not Qualified
Number of Outputs 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Max Power Dissipation 1.25W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.50Lx0.40W x 0.30 H 12.8mmx10.1mmx7.6mm
Series ECONOLINE RN (1.25W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 1.9g
Number of Pins 4
Package / Case 8-DIP Module, 4 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
