RM-053.3S/P
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 0.25W 05VIN 3.3VOUT
PDF
/
Inventory: 8796
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XSMA-T4
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 70%
Voltage - Isolation 1kV
Voltage - Input (Max) 5.5V
Output Voltage 3.3V
Max Output Current 76mA
Voltage - Input (Min) 4.5V
Input Voltage-Nom 15V
Trim/Adjustable Output NO
Output Current 76mA
Output Power 250mW
Max Output Voltage 3.3V
Total Power Output-Max 0.25W
Nominal Input Voltage 5V
Max Power Dissipation 250mW
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.45Lx0.24W x 0.39 H 11.5mmx6.0mmx10.0mm
Series ECONOLINE RM (0.25W)
Packaging Tube
Operating Temperature -40°C~85°C
Dimensions
Height 10mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 1.4g
Package / Case 4-SIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
