RK-1209S/P
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 12VIN 09VOUT
PDF
/
Inventory: 1253
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
JESD-30 Code R-PSIP-T7
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 84%
Voltage - Isolation 3kV
Voltage - Input (Max) 13.2V
Output Voltage 9V
Max Output Current 111mA
Voltage - Input (Min) 10.8V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Output Current 111mA
Output Power 1W
Max Output Voltage 9V
Total Power Output-Max 1W
Nominal Input Voltage 12V
Pin Count 7/4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.77Lx0.24W x 0.40 H 19.7mmx6.0mmx10.2mm
Series ECONOLINE RK (1W)
Packaging Tube
Operating Temperature -40°C~85°C
Dimensions
Height 10.2mm
Width 6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 2.6g
Package / Case 7-SIP Module, 4 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
