REM6-1205D/A
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 6W 9-18Vin +/-5Vout DIP24
PDF
/
Inventory: 1186
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 10.4mm
Technical
Voltage - Output 2 -5V
Max Output Voltage 5V
Output Power 6W
Output Current 600mA
Current - Output (Max) 600mA 600mA
Voltage - Input (Min) 9V
Max Output Current 600mA
Output Voltage 5V
Voltage - Input (Max) 18V
Voltage - Isolation 5kV
Efficiency 85%
Number of Outputs 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 6W
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, OCP, OVP, SCP, UVLO
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Series MEDLINE REM6 (6W)
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Weight 14g
Package / Case 24-DIP Module, 6 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
