REM3-2412SW/A
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 3W 9-36Vin 12Vout DIP24
PDF
/
Buying Options
Total Price: USD $71.96
Unit Price: USD $71.96119
≥1 USD $71.96119
≥10 USD $67.88791
≥100 USD $64.0452
≥500 USD $60.42
≥1000 USD $57
≥3000 USD $53.77358
Inventory: 2418
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 5 Leads
Weight 14g
Technical
Operating Temperature -40°C~105°C
Packaging Tube
Series MEDLINE REM3 (3W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Feature Remote On/Off, OCP, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Max Power Dissipation 3W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
Terminal Pitch 2.54mm
JESD-30 Code R-PDMA-P5
Number of Outputs 1
Efficiency 87%
Voltage - Isolation 5kV
Voltage - Input (Max) 36V
Output Voltage 12V
Max Output Current 250mA
Voltage - Input (Min) 9V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Output Current 250mA
Output Power 3W
Max Output Voltage 12V
Total Power Output-Max 3W
Dimensions
Height 10.4mm
Width 20.3mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
