REM10-243.3SW/A/CTRL
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 10W 9-36Vin 3.3Vout DIP24
PDF
/
Inventory: 5662
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 20.3mm
Height 10.4mm
Technical
Warm-up Time 0.03 s
Switching Frequency-Max 330kHz
Total Power Output-Max 8.25W
Control Mode VOLTAGE-MODE
Protections OVER CURRENT; OUTPUT OVER VOLTAGE; OVERLOAD
Max Output Voltage 3.3V
Control Features Enable, Active Low
Output Power 10W
Output Current 2.5A
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 9V
Max Output Current 2.5A
Output Voltage 3.3V
Voltage - Input (Max) 36V
Voltage - Isolation 5kV
Efficiency 83%
Number of Outputs 1
JESD-30 Code R-PDMA-P24/7
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 10W
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OCP, OVP, SCP, UVLO
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Series MEDLINE REM10 (10W)
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Weight 14g
Package / Case 24-DIP Module, 6 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
