REM10-2412D/A
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 10W 18-36Vin +/-12Vout DIP24
PDF
/
Buying Options
Total Price: USD $75.47
Unit Price: USD $75.473492
≥1 USD $75.473492
≥10 USD $71.201401
≥100 USD $67.171137
≥500 USD $63.368995
≥1000 USD $59.782076
Inventory: 6480
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 6 Leads
Weight 14g
Technical
Operating Temperature -40°C~105°C
Packaging Tube
Series MEDLINE REM10 (10W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
JESD-609 Code e3
Feature Remote On/Off, OCP, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Terminal Finish Tin (Sn)
Applications ITE (Commercial), Medical
Power Rating 10W
Max Power Dissipation 10W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 10.4mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-P7
Number of Outputs 2
Efficiency 89%
Voltage - Isolation 5kV
Output Voltage 12V
Max Output Current 125mA
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 416mA 416mA
Output Current 416mA
Output Power 10W
Control Features Enable, Active Low
Max Output Voltage 12V
Voltage - Output 2 -12V
Current - Output 1 416mA
Nominal Input Voltage 24V
Max Output Power 10W
Current - Output 2 416mA
Max Input Voltage (DC) 36V
Min Input Voltage (DC) 18V
Dimensions
Height 10.4mm
Length 31.8mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
