REM10-1215S/C
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 10W 9-18Vin 15Vout DIP24
PDF
/
Inventory: 5019
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 5 Leads
Weight 14g
Technical
Operating Temperature -40°C~105°C
Packaging Tube
Series MEDLINE REM10 (10W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
JESD-609 Code e3
Feature Remote On/Off, OCP, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Terminal Finish Tin (Sn)
Applications ITE (Commercial), Medical
Max Power Dissipation 10W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
Terminal Pitch 2.54mm
JESD-30 Code R-PDMA-P7
Number of Outputs 1
Efficiency 89%
Voltage - Isolation 5kV
Voltage - Input (Max) 18V
Output Voltage 15V
Max Output Current 670mA
Voltage - Input (Min) 9V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Output Current 670mA
Output Power 10W
Control Features Enable, Active Low
Max Output Voltage 15V
Dimensions
Height 10.4mm
Width 20.3mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
