REM10-0505D/A
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 10W 4.5-9Vin +/-5Vout DIP24
PDF
/
Inventory: 7864
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Max Output Voltage 5V
Voltage - Output 2 -5V
Control Features Enable, Active Low
Output Power 10W
Output Current 1A
Current - Output (Max) 1A 1A
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 300mA
Output Voltage 5V
Voltage - Input (Max) 9V
Voltage - Isolation 5kV
Efficiency 83%
Number of Outputs 2
JESD-30 Code R-PDMA-P7
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 10W
Applications ITE (Commercial), Medical
Terminal Finish Tin (Sn)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, OCP, OVP, SCP, UVLO
JESD-609 Code e3
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Series MEDLINE REM10 (10W)
Packaging Tube
Operating Temperature -40°C~105°C
Dimensions
Height 10.4mm
Length 31.8mm
Physical
Weight 14g
Package / Case 24-DIP Module, 6 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
