REC6-0515DRW/R8/C
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 9 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 6W 4.5-9VIN +/-15VOUT
PDF
/
Buying Options
Total Price: USD $55.55
Unit Price: USD $55.54899
≥1 USD $55.54899
≥10 USD $52.4047
≥100 USD $49.4384
≥500 USD $46.64
≥1000 USD $44
≥3000 USD $41.50943
Inventory: 7337
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 9 Leads
Weight 14g
Technical
Operating Temperature -40°C~75°C
Packaging Tube
Series ECONOLINE REC6/R (6W)
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Subcategory Other Analog ICs
Max Power Dissipation 5W
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-T9
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 80%
Voltage - Isolation 8kV
Voltage - Input (Max) 9V
Output Voltage 15V
Max Output Current 167mA
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Trim/Adjustable Output NO
Current - Output (Max) 167mA 167mA
Output Current 167mA
Output Power 6W
Max Output Voltage 15V
Voltage - Output 2 -15V
Total Power Output-Max 6W
Nominal Input Voltage 5V
Dimensions
Height 10.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
