REC5A-0505SW/H2
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 5V 5W
PDF
/
Buying Options
Total Price: USD $12.67
Unit Price: USD $12.672
≥1 USD $12.672
≥10 USD $12.5752
≥100 USD $12.4784
≥500 USD $12.286912
≥1000 USD $11.90288
≥3000 USD $10.850488
Inventory: 337
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Package / Case 24-DIP Module, 8 Leads
Surface Mount NO
Weight 13g
Technical
Operating Temperature -40°C~100°C With Derating
Packaging Tube
Series REC5A (5W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Type Isolated Module
Applications ITE (Commercial)
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code unknown
JESD-30 Code R-PDMA-P8
Number of Outputs 1
Efficiency 73.5%
Voltage - Isolation 2kV
Voltage - Input (Max) 9V
Output Voltage 5V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Trim/Adjustable Output NO
Current - Output (Max) 1A
Output Current 1A
Output Power 5W
Max Output Voltage 5V
Total Power Output-Max 5W
Dimensions
Height 10.2mm
Width 20.3mm
Compliance
RoHS Status ROHS3 Compliant
