REC5-483.3SRWZ/H2/A/CTRL
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 5W 18-72VIN 3.3VOUT
PDF
/
Inventory: 6107
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Subcategory Other Analog ICs
Max Power Dissipation 5W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-P9
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 76%
Voltage - Isolation 2kV
Voltage - Input (Max) 72V
Output Voltage 3.3V
Max Output Current 1A
Voltage - Input (Min) 18V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Output Current 1A
Output Power 5W
Control Features Enable, Active Low
Max Output Voltage 3.3V
Total Power Output-Max 3.3W
Nominal Input Voltage 48V
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Series ECONOLINE REC5 (5W)
Packaging Tube
Operating Temperature -40°C~75°C
Dimensions
Height 10.2mm
Length 32mm
Width 20.3mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Weight 13g
Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
