REC5-4809DRWZ/H/B/M
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 12 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 5W 18-72VIN +/-09VOUT
PDF
/
Buying Options
Total Price: USD $60.35
Unit Price: USD $60.346136
≥1 USD $60.346136
≥195 USD $24.078586
≥495 USD $23.273778
≥1005 USD $22.87597
Inventory: 994
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 12 Leads
Weight 13g
Technical
Operating Temperature -40°C~75°C
Packaging Tube
Series ECONOLINE REC5 (5W)
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 5W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 84%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 72V
Output Voltage 9V
Max Output Current 278mA
Voltage - Input (Min) 18V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 278mA 278mA
Output Current 278mA
Output Power 5W
Max Output Voltage 9V
Voltage - Output 2 -9V
Total Power Output-Max 5W
Nominal Input Voltage 48V
Dimensions
Height 10.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
