REC5-2412DRW/H6/A/CTRL
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 9 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 5W 18-36VIN +/-12VOUT
PDF
/
Buying Options
Total Price: USD $60.05
Unit Price: USD $60.050733
≥1 USD $60.050733
≥195 USD $23.960425
≥495 USD $23.159556
≥1005 USD $22.764373
Inventory: 9167
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 9 Leads
Number of Pins 9
Weight 13g
Technical
Operating Temperature -40°C~75°C
Packaging Tube
Series ECONOLINE REC5 (5W)
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Feature Remote On/Off, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
Type Isolated Module
Applications ITE (Commercial), Medical
Subcategory Other Analog ICs
Max Power Dissipation 5W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 20.3mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 85%
Voltage - Isolation 6kV
Voltage - Input (Max) 36V
Output Voltage 12V
Max Output Current 210mA
Voltage - Input (Min) 18V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 210mA 210mA
Output Current 210mA
Output Power 5W
Control Features Enable, Active Low
Max Output Voltage 12V
Voltage - Output 2 -12V
Total Power Output-Max 5W
Nominal Input Voltage 24V
Isolation Isolated
Dimensions
Height 10.2mm
Compliance
RoHS Status ROHS3 Compliant
