REC5-1209DRW/H2/A/CTRL
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 9 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 5W 9-18VIN +/-09VOUT
PDF
/
Inventory: 3876
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 10.2mm
Technical
Nominal Input Voltage 12V
Total Power Output-Max 5W
Voltage - Output 2 -9V
Max Output Voltage 9V
Control Features Enable, Active Low
Output Power 5W
Output Current 278mA
Current - Output (Max) 278mA 278mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Max Output Current 278mA
Output Voltage 9V
Voltage - Input (Max) 18V
Voltage - Isolation 2kV
Efficiency 84%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-PDMA-P9
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 5W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Series ECONOLINE REC5 (5W)
Packaging Tube
Operating Temperature -40°C~75°C
Physical
Weight 13g
Package / Case 24-DIP Module, 9 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
