REC5-1205DRW/H2/A/CTRL
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 9 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-5V 5W
PDF
/
Buying Options
Total Price: USD $31.56
Unit Price: USD $31.56192
≥1 USD $31.56192
≥10 USD $29.7754
≥100 USD $28.09
≥500 USD $26.5
≥1000 USD $25
≥3000 USD $23.58491
Inventory: 1448
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 10.2mm
Technical
Isolation Isolated
Nominal Input Voltage 12V
Total Power Output-Max 5W
Voltage - Output 2 -5V
Max Output Voltage 5V
Control Features Enable, Active Low
Output Power 5W
Output Current 500mA
Current - Output (Max) 500mA 500mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Input (Min) 9V
Max Output Current 500mA
Output Voltage 5V
Voltage - Input (Max) 18V
Voltage - Isolation 2kV
Efficiency 81%
Qualification Status Not Qualified
Number of Outputs 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 20.3mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 5W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Series ECONOLINE REC5 (5W)
Packaging Tube
Operating Temperature -40°C~75°C
Physical
Weight 13g
Number of Pins 9
Package / Case 24-DIP Module, 9 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
