REC5-0512SRW/H2/A/M/CTRL
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 5W 4.5-9VIN 12VOUT
PDF
/
Buying Options
Total Price: USD $30.3
Unit Price: USD $30.29945
≥1 USD $30.29945
≥10 USD $28.58438
≥100 USD $26.9664
≥500 USD $25.44
≥1000 USD $24
≥3000 USD $22.64151
Inventory: 5945
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 20.3mm
Length 32mm
Height 10.2mm
Technical
Nominal Input Voltage 5V
Total Power Output-Max 5W
Max Output Voltage 12V
Control Features Enable, Active Low
Output Power 5W
Output Current 420mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 420mA
Output Voltage 12V
Voltage - Input (Max) 9V
Voltage - Isolation 2kV
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-MDMA-P9
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 5W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Series ECONOLINE REC5 (5W)
Packaging Tube
Operating Temperature -40°C~75°C
Physical
Weight 13g
Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
