REC3.5-2409DRW/R10/A/CTRL

Recom Power
RoHS
RoHS RoHS compliant
Package 24-DIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description CONV DC/DC 3.5W 18-36VIN +/-09VO
PDF
/
Inventory: 7579
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 7 Leads
Weight 14g

Technical

Operating Temperature -40°C~85°C
Packaging Tube
Series ECONOLINE REC3.5/R (3.5W)
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Feature Remote On/Off, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Subcategory Other Analog ICs
Max Power Dissipation 3.5W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-P7
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 82%
Voltage - Isolation 10kV
Voltage - Input (Max) 36V
Output Voltage 9V
Max Output Current 194mA
Voltage - Input (Min) 18V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 194mA 194mA
Output Current 194mA
Output Power 3.5W
Control Features Enable, Active Low
Max Output Voltage 9V
Voltage - Output 2 -9V
Nominal Input Voltage 24V

Dimensions

Height 10.2mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
