REC3.5-0515SRW/R10/A/CTRL/X1
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 3.5W 4.5-9VIN 15VOUT
PDF
/
Inventory: 5431
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 20.3mm
Length 32mm
Height 10.2mm
Technical
Nominal Input Voltage 5V
Max Output Voltage 15V
Control Features Enable, Active Low
Output Power 3.5W
Output Current 233mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 233mA
Output Voltage 15V
Voltage - Input (Max) 9V
Voltage - Isolation 10kV
Efficiency 83%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PDMA-P7
Pin Count 24/7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 3.5W
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, SCP, UVLO
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Series ECONOLINE REC3.5/R (3.5W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 14g
Package / Case 24-DIP Module, 7 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
