REC3-2409DRWZ/H2/A/M/CTRL
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 3W 9-36VIN +/-09VOUT
PDF
/
Inventory: 4956
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 20.3mm
Length 32mm
Height 10.2mm
Technical
Nominal Input Voltage 24V
Max Input Voltage 36V
Min Input Voltage 9V
Voltage - Output 2 -9V
Max Output Voltage 9V
Control Features Enable, Active Low
Output Power 3W
Output Current 165mA
Current - Output (Max) 165mA 165mA
Voltage - Input (Min) 9V
Voltage - Output 1 9V
Max Output Current 165mA
Output Voltage 9V
Voltage - Input (Max) 36V
Voltage - Isolation 2kV
Efficiency 83%
Number of Outputs 2
Max Power Dissipation 3W
Power (Watts) 3W
Applications ITE (Commercial)
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Series ECONOLINE REC3-DRW (3W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 13g
Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
