REC3-1209SRW/H4/C/SMD-R
RoHS
RoHS compliant
RoHS compliantPackage 24-SMD Module, 18 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 3W 9-18VIN 09VOUT
PDF
/
Inventory: 3317
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-SMD Module, 18 Leads
Weight 13g
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series ECONOLINE REC3-SRW (3W)
Size / Dimension 1.26Lx0.78W x 0.44 H 32.0mmx19.9mmx11.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Subcategory Other Analog ICs
Max Power Dissipation 3W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 2.54mm
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 83%
Voltage - Isolation 4kV
Voltage - Input (Max) 18V
Output Voltage 9V
Max Output Current 330mA
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Output Current 330mA
Output Power 3W
Max Output Voltage 9V
Total Power Output-Max 2.97W
Nominal Input Voltage 12V
Dimensions
Height 10.9mm
Compliance
RoHS Status ROHS3 Compliant
