REC3-0512SRW/H2/A/SMD
RoHS
RoHS compliant
RoHS compliantPackage 24-SMD Module, 18 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 3W 4.5-9VIN 12VOUT
PDF
/
Inventory: 10031
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-SMD Module, 18 Leads
Weight 13g
Technical
Operating Temperature -40°C~80°C
Packaging Tube
Series ECONOLINE REC3-SRW (3W)
Size / Dimension 1.26Lx0.78W x 0.44 H 32.0mmx19.9mmx11.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 3W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 2.54mm
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 85%
Voltage - Isolation 2kV
Voltage - Input (Max) 9V
Output Voltage 12V
Max Output Current 250mA
Nominal Input Voltage 5V
Total Power Output-Max 3W
Max Output Voltage 12V
Output Power 3W
Output Current 250mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 10.9mm
