REC20-4815D
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 20W 36-75VIN +/-15VOU
PDF
/
Buying Options
Total Price: USD $42.11
Unit Price: USD $42.111268
≥1 USD $42.111268
Inventory: 9569
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 50.8mm
Height 10.2mm
Technical
Max Output Voltage -15V
Control Features Enable, Active High
Output Power 20W
Output Current 670mA
Current - Output (Max) 670mA 670mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 15V
Max Output Current 670mA
Output Voltage -15V
Voltage - Input (Max) 75V
Voltage - Isolation 1.6kV
Efficiency 90.5%
Number of Outputs 2
JESD-30 Code R-PDMA-P6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 20W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, OVP, SCP, UVLO
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Series ECONOLINE REC20 (20W)
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Weight 27g
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
