REC20-4812S
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 20W 36-75VIN 12VOUT T
PDF
/
Buying Options
Total Price: USD $40.1
Unit Price: USD $40.102531
≥1 USD $40.102531
Inventory: 7064
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module
Weight 27g
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE REC20 (20W)
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Feature Remote On/Off, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 20W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-P6
Number of Outputs 1
Efficiency 89%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 75V
Output Voltage 10.8V
Max Output Current 1.67A
Voltage - Output 1 12V
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Output Current 1.67A
Output Power 20W
Control Features Enable, Active High
Max Output Voltage 13.2V
Dimensions
Height 10.2mm
Length 50.8mm
Width 25.4mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
