RE-1515S/H
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 15VIN 15VOUT
PDF
/
Inventory: 1138
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 7-SIP Module, 4 Leads
Number of Pins 4
Weight 2.2g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series ECONOLINE RE (1W)
Size / Dimension 0.77Lx0.24W x 0.40 H 19.7mmx6.0mmx10.2mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 1W
Technology HYBRID
Terminal Position SINGLE
Number of Functions 1
Depth 6mm
Number of Outputs 1
Efficiency 84%
Voltage - Isolation 2kV
Voltage - Input (Max) 16.5V
Output Voltage 15V
Max Output Current 66mA
Voltage - Input (Min) 13.5V
Input Voltage-Nom 15V
Trim/Adjustable Output NO
Output Current 66mA
Output Power 1W
Max Output Voltage 15V
Total Power Output-Max 1W
Nominal Input Voltage 15V
Isolation Isolated
Dimensions
Height 10.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
