RE-0512S/P
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 5VIN 12VOUT
PDF
/
Inventory: 1526
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Height 10.2mm
Technical
Nominal Input Voltage 5V
Total Power Output-Max 1W
Max Output Voltage 12V
Output Power 1W
Output Current 83mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 83mA
Output Voltage 12V
Voltage - Input (Max) 5.5V
Voltage - Isolation 1kV
Efficiency 84%
Number of Outputs 1
JESD-30 Code R-PSMA-T4
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.24W x 0.40 H 19.7mmx6.0mmx10.2mm
Series ECONOLINE RE (1W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 2.2g
Package / Case 7-SIP Module, 4 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
