RD-2412D/HP
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 24VIN +/-12VOUT
PDF
/
Buying Options
Total Price: USD $9.59
Unit Price: USD $9.592
≥1 USD $9.592
≥10 USD $9.51808
≥100 USD $9.44592
≥500 USD $9.300544
≥1000 USD $9.009792
≥3000 USD $8.228
Inventory: 134
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.05mm
Length 19.65mm
Height 10.2mm
Technical
Nominal Input Voltage 24V
Total Power Output-Max 2W
Voltage - Output 2 -12V
Max Output Voltage 12V
Output Power 2W
Output Current 84mA
Current - Output (Max) 84mA 84mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 21.6V
Max Output Current 84mA
Output Voltage 12V
Voltage - Input (Max) 26.4V
Voltage - Isolation 2kV
Efficiency 84%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XSMA-T5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 2W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.28W x 0.40 H 19.7mmx7.1mmx10.2mm
Series ECONOLINE RD (2W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 2.8g
Package / Case 7-SIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
