RD-1205D
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-5V 2W
PDF
/
Buying Options
Total Price: USD $7.36
Unit Price: USD $7.3568
≥1 USD $7.3568
≥10 USD $7.29168
≥100 USD $7.23624
≥500 USD $7.12448
≥1000 USD $6.902016
≥3000 USD $6.3008
Inventory: 1561
Minimum: 1
-
+
Technical Details
Technical
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Additional Feature ALSO AVAILABLE OUTPUT VOLTAGE: -5V; SEATED HGT CALCULATED
Subcategory Other Analog ICs
Power Rating 2W
Max Power Dissipation 2W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 19.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XSMA-T5
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 82%
Voltage - Isolation 1kV
Output Voltage 5V
Max Output Current 200mA
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 200mA 200mA
Output Current 200mA
Output Power 2W
Max Output Voltage 5V
Current - Output 1 200mA
Nominal Input Voltage 12V
Max Output Power 2W
Nominal Output Voltage -5V
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.28W x 0.40 H 19.7mmx7.1mmx10.2mm
Series ECONOLINE RD (2W)
Packaging Tube
Operating Temperature -40°C~85°C
Current - Output 2 200mA
Max Input Voltage (DC) 13.2V
Min Input Voltage (DC) 10.8V
Physical
Weight 2.8g
Package / Case 7-SIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
Dimensions
Height 10.2mm
Width 7.05mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
