RD-0524D/H
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-24V 2W
PDF
/
Inventory: 1183
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.05mm
Length 19.65mm
Height 10.2mm
Technical
Total Power Output-Max 2W
Voltage - Output 2 -24V
Max Output Voltage 24V
Output Current 42mA
Current - Output (Max) 42mA 42mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 42mA
Output Voltage 24V
Voltage - Input (Max) 5.5V
Voltage - Isolation 2kV
Efficiency 86%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XSMA-T5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 2W
Subcategory Other Analog ICs
Power (Watts) 2W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.77Lx0.28W x 0.40 H 19.7mmx7.1mmx10.2mm
Series ECONOLINE RD (2W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 2.8g
Package / Case 7-SIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
