RB-3.33.3S
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 3.3VIN 3.3VOUT
PDF
/
Buying Options
Total Price: USD $6.2
Unit Price: USD $6.204
≥1 USD $6.204
≥10 USD $6.11776
≥100 USD $6.02888
≥500 USD $5.851296
≥1000 USD $5.674064
≥3000 USD $5.496744
Inventory: 27
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 7-SIP Module, 5 Leads
Number of Pins 5
Weight 2.2g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series ECONOLINE RB (1W)
Size / Dimension 0.77Lx0.24W x 0.40 H 19.7mmx6.0mmx10.2mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 1W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 6mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 7/5
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 75%
Voltage - Isolation 1kV
Voltage - Input (Max) 3.6V
Output Voltage 3.3V
Max Output Current 303mA
Voltage - Input (Min) 3V
Input Voltage-Nom 3.3V
Trim/Adjustable Output NO
Output Current 303mA
Output Power 1W
Max Output Voltage 3.3V
Total Power Output-Max 0.999W
Nominal Input Voltage 3.3V
Isolation Isolated
Dimensions
Height 10.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
