RB-3.33.3D
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 3.3VIN +/-3.3VOUT
PDF
/
Buying Options
Total Price: USD $6.52
Unit Price: USD $6.5208
≥1 USD $6.5208
≥10 USD $6.424
≥100 USD $6.33072
≥500 USD $6.144864
≥1000 USD $5.95848
≥3000 USD $5.772272
Inventory: 54
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 10.2mm
Technical
Isolation Isolated
Nominal Input Voltage 3.3V
Voltage - Output 2 -3.3V
Max Output Voltage 3.3V
Output Power 1W
Output Current 152mA
Current - Output (Max) 152mA 152mA
Trim/Adjustable Output NO
Input Voltage-Nom 3.3V
Voltage - Input (Min) 3V
Max Output Current 152mA
Output Voltage 3.3V
Voltage - Input (Max) 3.6V
Voltage - Isolation 1kV
Efficiency 70%
Qualification Status Not Qualified
Number of Outputs 2
Pin Count 7/5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 6mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.24W x 0.40 H 19.7mmx6.0mmx10.2mm
Series ECONOLINE RB (1W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 2.2g
Number of Pins 5
Package / Case 7-SIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
