RB-2412S/HP

Recom Power
RoHS
RoHS RoHS compliant
Package 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description CONV DC/DC 1W 24VIN 12VOUT
PDF
/
Inventory: 1107
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 7-SIP Module, 5 Leads
Weight 2.2g

Technical

Operating Temperature -40°C~85°C
Packaging Tube
Series ECONOLINE RB (1W)
Size / Dimension 0.77Lx0.24W x 0.40 H 19.7mmx6.0mmx10.2mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Subcategory Other Analog ICs
Max Power Dissipation 1W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 7/5
JESD-30 Code R-XSMA-P5
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 80%
Voltage - Isolation 2kV
Voltage - Input (Max) 26.4V
Output Voltage 12V
Max Output Current 84mA
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Output Current 84mA
Output Power 1W
Max Output Voltage 12V
Nominal Input Voltage 24V

Dimensions

Height 10.2mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
