R2S8-1509-R
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 15VIN 9VOUT SMD
PDF
/
Inventory: 4086
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 8.7mm
Technical
Nominal Input Voltage 15V
Max Output Voltage 9V
Output Power 2W
Output Current 222mA
Voltage - Input (Min) 13.5V
Max Output Current 222mA
Output Voltage 9V
Voltage - Input (Max) 16.5V
Voltage - Isolation 1kV
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PDSO-G8
Terminal Pitch 2.54mm
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 2W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.50Lx0.42W x 0.35 H 12.8mmx10.7mmx9.0mm
Series ECONOLINE R2S (2W)
Packaging Tape & Reel (TR)
Operating Temperature -40°C~100°C
Physical
Weight 1.5g
Package / Case 8-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
