R2S12-2409
RoHS
RoHS compliant
RoHS compliantPackage 12-SMD Module, 10 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 9V 2W
PDF
/
Inventory: 5769
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 12-SMD Module, 10 Leads
Number of Pins 5
Weight 1.6g
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE R2S (2W)
Size / Dimension 0.60Lx0.42W x 0.35 H 15.2mmx10.7mmx9.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 2W
Terminal Position DUAL
Terminal Form GULL WING
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 85%
Voltage - Isolation 1kV
Voltage - Input (Max) 26.4V
Output Voltage 9V
Max Output Current 222mA
Voltage - Input (Min) 21.6V
Output Current 222mA
Output Power 2W
Max Output Voltage 9V
Nominal Input Voltage 24V
Dimensions
Height 8.7mm
Compliance
RoHS Status ROHS3 Compliant
