R2D12-2409/P
RoHS
RoHS compliant
RoHS compliantPackage 12-SMD Module, 10 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W +/-9VOUT SMD
PDF
/
Inventory: 9462
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Current - Output (Max) 111mA 111mA
Output Current 111mA
Output Power 2W
Max Output Voltage 9V
Voltage - Output 2 -9V
Nominal Input Voltage 24V
Voltage - Input (Min) 21.6V
Max Output Current 111mA
Output Voltage 9V
Voltage - Input (Max) 26.4V
Voltage - Isolation 1kV
Efficiency 80%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-PDSO-G10
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 2W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.60Lx0.42W x 0.35 H 15.2mmx10.7mmx9.0mm
Series ECONOLINE R2D (2W)
Packaging Tube
Operating Temperature -40°C~100°C
Dimensions
Height 8.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 1.6g
Number of Pins 6
Package / Case 12-SMD Module, 10 Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
