R2D12-2409/HP
RoHS
RoHS compliant
RoHS compliantPackage 12-SMD Module, 10 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W +/-9VOUT SMD
PDF
/
Inventory: 2875
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 8.7mm
Technical
Nominal Input Voltage 24V
Voltage - Output 2 -9V
Max Output Voltage 9V
Output Power 2W
Output Current 111mA
Current - Output (Max) 111mA 111mA
Voltage - Input (Min) 21.6V
Max Output Current 111mA
Output Voltage 9V
Voltage - Input (Max) 26.4V
Voltage - Isolation 3kV
Efficiency 80%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-PDSO-G10
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 2W
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.60Lx0.42W x 0.35 H 15.2mmx10.7mmx9.0mm
Series ECONOLINE R2D (2W)
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Weight 1.6g
Package / Case 12-SMD Module, 10 Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
