R2D12-0512/H
RoHS
RoHS compliant
RoHS compliantPackage 12-SMD Module, 10 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W +/-12VOUT SMD
PDF
/
Inventory: 9177
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 8.7mm
Technical
Isolation Isolated
Nominal Input Voltage 5V
Voltage - Output 2 -12V
Max Output Voltage 12V
Output Power 2W
Output Current 83mA
Current - Output (Max) 83mA 83mA
Voltage - Input (Min) 4.5V
Max Output Current 83mA
Output Voltage 12V
Voltage - Input (Max) 5.5V
Voltage - Isolation 3kV
Efficiency 83%
Qualification Status Not Qualified
Number of Outputs 2
Depth 10.7mm
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 2W
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.60Lx0.42W x 0.35 H 15.2mmx10.7mmx9.0mm
Series ECONOLINE R2D (2W)
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Weight 1.6g
Number of Pins 10
Package / Case 12-SMD Module, 10 Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
