R2D10-2412

Recom Power
RoHS
RoHS RoHS compliant
Package 10-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description CONV DC/DC 2W +/-12VOUT SMD
PDF
/
Buying Options
Total Price: USD $14.2
Unit Price: USD $14.2004
≥1 USD $14.2004
≥10 USD $13.396596
≥100 USD $12.638306
≥500 USD $11.922925
≥1000 USD $11.248042
Inventory: 1153
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-SMD Module
Weight 1.5g

Technical

Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE R2D (2W)
Size / Dimension 0.60Lx0.42W x 0.35 H 15.2mmx10.7mmx9.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 2W
Terminal Position DUAL
Terminal Form GULL WING
JESD-30 Code R-PDSO-G10
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 85%
Voltage - Isolation 1kV
Voltage - Input (Max) 26.4V
Output Voltage 12V
Max Output Current 83mA
Voltage - Input (Min) 21.6V
Current - Output (Max) 83mA 83mA
Output Current 83mA
Output Power 2W
Max Output Voltage 12V
Voltage - Output 2 -12V
Nominal Input Voltage 24V

Dimensions

Height 8.7mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
