R2D10-1515
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W +/-15VOUT SMD
PDF
/
Inventory: 1845
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 8.7mm
Technical
Nominal Input Voltage 15V
Voltage - Output 2 -15V
Max Output Voltage 15V
Output Power 2W
Output Current 66mA
Current - Output (Max) 66mA 66mA
Voltage - Input (Min) 13.5V
Max Output Current 66mA
Output Voltage 15V
Voltage - Input (Max) 16.5V
Voltage - Isolation 1kV
Efficiency 70 ~ 80%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-PDSO-G10
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 2W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.60Lx0.42W x 0.35 H 15.2mmx10.7mmx9.0mm
Series ECONOLINE R2D (2W)
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Weight 1.5g
Package / Case 10-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
