R2D10-1512/P

Recom Power
RoHS
RoHS RoHS compliant
Package 10-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description CONV DC/DC 2W +/-12VOUT SMD
PDF
/
Inventory: 3196
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height 8.7mm

Technical

Nominal Input Voltage 15V
Voltage - Output 2 -12V
Max Output Voltage 12V
Output Power 2W
Output Current 83mA
Current - Output (Max) 83mA 83mA
Voltage - Input (Min) 13.5V
Max Output Current 83mA
Output Voltage 12V
Voltage - Input (Max) 16.5V
Voltage - Isolation 1kV
Efficiency 70 ~ 80%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-PDSO-G10
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 2W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.60Lx0.42W x 0.35 H 15.2mmx10.7mmx9.0mm
Series ECONOLINE R2D (2W)
Packaging Tube
Operating Temperature -40°C~100°C

Physical

Weight 1.5g
Package / Case 10-SMD Module
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 10 Weeks
