R2D10-1205/P
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W +/-5VOUT SMD
PDF
/
Inventory: 7125
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-SMD Module
Weight 1.5g
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE R2D (2W)
Size / Dimension 0.60Lx0.42W x 0.35 H 15.2mmx10.7mmx9.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 2W
Terminal Position DUAL
Terminal Form GULL WING
JESD-30 Code R-PDSO-G10
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 70 ~ 80%
Voltage - Isolation 1kV
Voltage - Input (Max) 13.2V
Output Voltage 5V
Max Output Current 100mA
Voltage - Input (Min) 10.8V
Current - Output (Max) 100mA 100mA
Output Current 200mA
Output Power 2W
Max Output Voltage 5V
Voltage - Output 2 -5V
Nominal Input Voltage 12V
Dimensions
Height 8.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
