R2D-2424/P
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 24VIN +/-24VOUT
PDF
/
Inventory: 8909
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-SMD Module, 6 Leads
Weight 1.5g
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE R2D (2W)
Size / Dimension 0.60Lx0.42W x 0.35 H 15.2mmx10.7mmx9.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Additional Feature SEATED HGT CALCULATED
Subcategory Other Analog ICs
Max Power Dissipation 2W
Technology HYBRID
Terminal Position DUAL
Terminal Form FLAT
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 30; 5
JESD-30 Code R-XDMA-F6
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 85%
Voltage - Isolation 1kV
Voltage - Input (Max) 26.4V
Output Voltage 24V
Max Output Current 42mA
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Nominal Input Voltage 24V
Total Power Output-Max 2W
Voltage - Output 2 -24V
Max Output Voltage 24V
Output Power 2W
Output Current 42mA
Current - Output (Max) 42mA 42mA
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10.7mm
Height 8.7mm
