R24P23.3S/P
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 24VIN 3.3VOUT
PDF
/
Inventory: 1131
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 4.3g
Number of Pins 4
Package / Case 7-SIP Module, 4 Leads
Technical
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 9.8mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 7/4
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 70%
Voltage - Isolation 6.4kV
Voltage - Input (Max) 26.4V
Output Voltage 3.3V
Max Output Current 600mA
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Output Current 600mA
Output Power 2W
Max Output Voltage 3.3V
Total Power Output-Max 2W
Nominal Input Voltage 24V
Isolation Isolated
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 2W
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.39W x 0.49 H 19.7mmx9.8mmx12.5mm
Series ECONOLINE RxxP2xx (2W)
Packaging Tube
Operating Temperature -40°C~85°C
Dimensions
Height 12.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
