R24P09D
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 24VIN +/-09VOUT
PDF
/
Buying Options
Total Price: USD $13.08
Unit Price: USD $13.0768
≥1 USD $13.0768
≥10 USD $12.96768
≥100 USD $12.86912
≥500 USD $12.670592
≥1000 USD $12.274768
≥3000 USD $11.202488
Inventory: 106
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 7-SIP Module, 5 Leads
Number of Pins 5
Weight 4.3g
Technical
Operating Temperature -40°C~90°C
Packaging Tube
Series ECONOLINE RxxPxx (1W)
Size / Dimension 0.77Lx0.39W x 0.49 H 19.7mmx9.8mmx12.5mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Max Power Dissipation 1W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 9.8mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 7/5
Number of Outputs 2
Efficiency 75%
Voltage - Isolation 6.4kV
Voltage - Input (Max) 26.4V
Output Voltage 9V
Max Output Current 55mA
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 55mA 55mA
Output Current 55mA
Output Power 1W
Max Output Voltage 9V
Voltage - Output 2 -9V
Total Power Output-Max 1W
Nominal Input Voltage 24V
Isolation Isolated
Dimensions
Height 12.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
